U.S. Solid 1x22 Brass Electric Solenoid Valve 24VDC Normally Closed Viton Air Water Fuel

Description

Semi-direct lift valve operates from 0 PSI to a maximum pressure of 145 PSI (0 MPa to 1.0 MPa). Solid normally closed (N/C) electric solenoid valve is constructed with a durable brass body, two-way inlet and outlet ports with one inch (1") female threaded (NPT) connections, and heat and oil resistant Viton gasket. Solid Normally Closed Electric Solenoid Valve; 1"ports, brass body, Viton seal, 24 volt DC, for air, water, or oil U. Manufactured in China. Operational pressure range for water: 0 to 101 PSI; for oil: 0 to 72 PSI; for air or gases: 0 to 101 PSI. Operational temperature range is 14 to 248 degrees Fahrenheit; -10 to +120 degrees Celsius. Valve is not intended to be energized continuously for more than 8 hours. This can lead to burnout of the coil, and malfunctioning of the valve. Quality assurance and/or conformity managed in accordance with standards: ISO 9001:2000; GB/T 19001:2000; European EN61000-6-1:2001 and EN61000-6-3:2001. Model: USS2-00064. Suitable for outdoor use; not for use underwater. 18 Watt power rating. 1" (25 mm) flow aperture permits a unidirectional flow capacity of 12 gallons per minute (GPM) of water at 60oFwith a pressure drop of 1 PSI (12 Cv). Suitable for use with hot or cold water, gas, air, very low viscosity fluids (< 20 cst), oils and hydrocarbons, e.g., gasoline, kerosene, or diesel fuel. The direct current coil energizes at 24 volts DC; voltage range + or - 10%.

Key Features

• The direct current coil energizes at 24 volts DC; voltage range + or - 10%.
• Suitable for outdoor use; not for use underwater.
• Suitable for use with hot or cold water, gas, air, very low viscosity fluids (< 20 cst), oils and hydrocarbons, e.g., gasoline, kerosene, or diesel fuel.
• 1" (25 mm) flow aperture permits a unidirectional flow capacity of 12 gallons per minute (GPM) of water at 60oFwith a pressure drop of 1 PSI (12 Cv).
• Solid normally closed (N/C) electric solenoid valve is constructed with a durable brass body, two-way inlet and outlet ports with one inch (1") female threaded (NPT) connections, and heat and oil resistant Viton gasket.
• Solid Normally Closed Electric Solenoid Valve; 1"ports, brass body, Viton seal, 24 volt DC, for air, water, or oil U.
